Quizzical is my submission to FBLA's 2021 Coding and Programming event. It can be found on GitHub.

This post provides technical documentation on how to build/run Quizzical from source code, as well as instructions on extending Quizzical's functionality. For help on the application itself, use the in-app Quizzical Help Pages instead.

Technical Background

Quizzical is built using the open source Electron framework, allowing it to run on all major desktop operating systems (Windows, Linux, and MacOS) with equivalent functionality. Electron Forge is used to handle development and builds.

NodeJS is required as a development dependency because of this, but users do not need it installed on their machines when running production builds as it's packaged into the app.

Core Features

Running Quizzical

Production builds can be run by directly launching the executable.

Development builds can by run using npm start in the app directory. If development dependencies are not yet installed, they can be installed using npm install.

Note: NodeJS v12 or later is required for development.

Building Quizzical

Quizzical comes with a make command to turn Quizzical into a production build (that can run on its own, without external dependencies).

You can build Quizzical using npm run make.

Quizzical Help Pages

End user help is available in the interactive help menu, accessible using the "Help" button in the toolbar. Questions are categorized by topic, and users can click on common questions to recieve more information in a separate page.

By placing the help option in the toolbar, users can access the help menu no matter where they are in the application.

Advanced Features

Modifying Questions

Questions are stored in a plain text file located under src/questions.txt, which is loaded into the application's memory upon startup. This makes it extremely easy to add, edit, or delete questions from the application. You can even make it about something completely unrelated to FBLA!

Question information is written in a semicolon delimited format, with the first "column" denoting the question type. For example, a multiple choice question begins with mc. Refer to the table below for all quesiton types:

After the question type, write out the question text, another semicolon, and then the answer to the question. In the case of multiple choice questions, additional options can be listed (again, semicolon delimited) after the answer. Quizzical will shuffle the answer options, so don't worry that the correct answer is always first in the file!

Example

Let's break down the first question in the questions.txt file:

mc;Which state was the first FBLA chapter chartered in?;Tennessee;Virginia;California;Delaware

The first "column" tells us that this is a multiple choice question. This is followed by the question itself (Which state was the first FBLA chapter chartered in?) and then the answer (Tennessee). Lastly, additional (incorrect) multiple choice options are listed - all separated by semicolons (Virginia;California;Delaware).

In Quizzical, this question would render like this:

Extending Quizzical

All significant portions of code are well documented to make extending Quizzical easy. Here's a list of important files to be aware of when modifying the application:

• Questions are stored in src/questions.txt. Refer to the section above for more details.
• Per Electron convention, the bulk of the code is written in the renderer script, located under src/window.js. This file is responsible for nearly everything you see in the window, and all its functions are documented to make extending/modifying easy.
• The backend, "privileged" script is located under src/index.js. This code is responsible for lower-level functionality such as creating the application window, displaying the menu bar, and showing system dialogs. The code here is minimal (but still documented) as it has full application-level permissions (i.e., arbitrary filesystem reading/writing).
• The Vue template is in src/index.html. On its own the index.html file is merely the "backbone" of the application, as it is the scripts that make it functional. Nonetheless, comments are included with a brief description of each page and what said page does.
• CSS is stored in src/index.css and is responsible for the aesthetics.
• Third party libraries are stored under the src/lib directory.
• The interactive help menu is its own separate "app", located under the src/help directory. It is designed to run standalone - separate from the rest of the application.

Post NLC Addendum

Quizzical placed 1st at Colorado's State Leadership Conference (SLC) and 7th at FBLA's National Leadership Conference (NLC). For reference, the 2021 NLC Topic has been included below.

Develop an original computer program to randomly generate a five-question FBLA quiz from a database. The program must complete a minimum of the following tasks:

• Have at least 50 questions in the database with the ability to see correct answers
• Include at least 4 types of questions (i.e. multiple choice, T/F, fill-in-the-blank, matching, and dropdown, etc.).
• Inform the user which questions were correctly answered
• Calculate the total correct on the five-question quiz
• Generate a printable report on quiz results
• Data must be stored persistently. Storage may be in a relational database, a document-oriented NoSQL database, flat text files, flat JSON, or XML files.
• All data entry must be validated with appropriate user notifications and error messages including the use of required fields
